MASTERMOVER STAINLESS STEEL ELECTRIC TUG | MT20/800+SS (8000KG)
MasterMover MT20/800+SS electric tug for controlled movement of wheeled loads; up to 8000 kg; slope rating 7 degrees; runtime 11.7 km; charge time 6h.
Key specs: Load: 8000 kg | Slope: 7º | Runtime: 11.7 km | IP: IP44
MasterMover MT20/800+SS electric tug for controlled movement of wheeled loads; up to 8000 kg; slope rating 7 degrees; runtime 11.7 km; charge time 6h.
MASTERMOVER STAINLESS STEEL ELECTRIC TUG | MT20/800+SS (8000KG) technical information
| Model | MT20/800+SS |
|---|---|
| Series | Stainless Steel |
| Load capacity | 8000 kg |
| Maximum load on castors | rails | 8,000 kg | 32,000 kg |
| Maximum force push | pull | 6,768 N | 6,768 N |
| Maximum slope | 7º |
| Runtime | 11.7 km |
| Charge time | 6h |
| Machine weight | 320 kg |
| Combined machine and battery weight | 460 kg |
| Drive type | Electric |
| Drive motor power | 2 kW |
| Standard machine speed | (Without two speed selector switch) 2 KPH |
| Voltage | 24 v |
| IP rating | IP44 |
| Dimensions (W x L x H) | 816 x 1447 x 1140 mm |
| Lithium battery runtime | 10.5 km |
| Lithium charge time | 4 hrs |
Before quotation review
- Confirm actual load weight, route distance, floor condition and gradient.
- Check castor, rail or wheel condition because rolling resistance changes the required tug capacity.
- Confirm coupling point, operator position, turning space and whether the machine is used indoors, outdoors, wet areas or controlled environments.
- For stainless steel, ATEX/IECEx, washdown or special-environment use, confirm documentation and site conditions before final recommendation.
Coupling options: CombiCoupling (male | female) Optional; BoxCoupling (male | female) Optional
Machine options: Additional Battery Optional; Flashing Safety Light and Motion Bleeper Optional; Two Speed Selector Switch Optional; Drive Wheel – 316 Stainless Steel Optional; Drive Wheel – 316 Stainless Steel Extra Grip Optional; Drive Wheel Extra Grip Optional
Technical information source: MasterMover series page | technical data sheet
Technical note: YKTOH series category route is not live yet.
