MASTERMOVER COMPACT ELECTRIC TUG | SM100 Tow (500KG)
MasterMover SM100 Tow electric tug for controlled movement of wheeled loads; up to 500 kg; slope rating 10 degrees; runtime 15.1 km; charge time 4.5h.
Key specs: Load: 500 kg | Slope: 10º | Runtime: 15.1 km | IP: IP42
MasterMover SM100 Tow electric tug for controlled movement of wheeled loads; up to 500 kg; slope rating 10 degrees; runtime 15.1 km; charge time 4.5h.
MASTERMOVER COMPACT ELECTRIC TUG | SM100 Tow (500KG) technical information
| Model | SM100 Tow |
|---|---|
| Series | SmartMover |
| Load capacity | 500 kg |
| Maximum load on castors | rails | 500 kg | 2,000 kg |
| Maximum force push | pull | 981 N | 981 N |
| Maximum slope | 10º |
| Runtime | 15.1 km |
| Charge time | 4.5h |
| Machine weight | 108 kg |
| Combined machine and battery weight | 125 kg |
| Drive type | Twin Electric Motor |
| Drive motor power | 2 x 0.22 kW |
| Standard machine speed | 4.2 KPH |
| Voltage | 24 v |
| IP rating | IP42 |
| Dimensions (W x L x H) | 412 x 944 x 978 mm |
| AGM battery runtime | 15. 1 km |
| AGM charge time | 4 hrs 30 mins |
| Lithium battery runtime | 25 km |
| Lithium charge time | 1 hrs 45 mins |
Before quotation review
- Confirm actual load weight, route distance, floor condition and gradient.
- Check castor, rail or wheel condition because rolling resistance changes the required tug capacity.
- Confirm coupling point, operator position, turning space and whether the machine is used indoors, outdoors, wet areas or controlled environments.
- For stainless steel, ATEX/IECEx, washdown or special-environment use, confirm documentation and site conditions before final recommendation.
Coupling options: Pin Coupling (male) Optional
Machine options: Additional AGM Battery Optional; Flashing Safety Light and Motion Bleeper Optional; Battery Protection System Standard; Two Speed Selector Swtich Standard
Technical information source: MasterMover series page | technical data sheet
