Zowell 1.5 Ton Deep Electric Pantograph Reach Truck

Double-deep electric pantograph reach truck for double-deep racking where stock is stored two pallets deep from one aisle.

Capacity: 1500 kg
Lift height: Up to 10160 mm; source also lists 8150 mm in the RRE115 specification table
Aisle / reach: 3023-3132 mm working aisle depending on pallet orientation

Overview

Zowell 1.5 Ton Deep Electric Pantograph Reach Truck is a YKTOH product listing adapted from manufacturer product information for warehouse equipment review.

Operating Fit

Pantograph reach structure allows access to the second pallet position in double-deep racking.
Source material states storage rate can increase by 40-50 percent compared with normal forklift or reach truck layouts.
Best suited to indoor operations with controlled pallet sizes and batch storage.

Key Specifications

Model / item no.	RRE15 / RRE115
Equipment type	Double-deep electric pantograph reach truck
Rated capacity	1500 kg
Lift height	Up to 10160 mm; source also lists 8150 mm in the RRE115 specification table
Aisle requirement	3023-3132 mm working aisle depending on pallet orientation
Control / guidance	Electric reach truck with pantograph-style reaching structure
Handling feature	Fork reach up to about 1030-1080 mm for double-deep racking
Best-fit use	Double-deep racking where stock is stored two pallets deep from one aisle.

Selection note: Final mast, battery, guidance, capacity, and aisle details should be confirmed against the customer’s site layout before quotation.
